64,587 Onwords | Ex-Showroom Chennai
Variants |
Variants | Showroom price | On road price |
DRUM BRAKE | 64587 | 72660 |
DISC BRAKE | 65552 | 73746 |
Performance |
Engine | Air-cooled, 4-stroke single cylinder OHC |
Engine displacement | 149.1 cc |
Maximum Power | 10 kW (13.4 BHP) @ 8000 RPM |
Maximum Torque | 12.80 Nm @ 5000 RPM |
Top speed | 101 kmph |
Acceleration (0-60Kmph) | 6 s |
Fuel Delivery System | Carburetor |
Cooling | Air cooling |
Ignition | Advanced Microprocessor Ignition System (AMI) |
Compression Ratio | 9.1 : 1 |
No of Cylinder | 1 |
Bore & Stroke | 57.3 x 57.8 mm |
Spark Plugs Per Cylinder | 1 |
Valves Per Cylinder | 2 |
Gear box | 5 Speed constant mesh |
Clutch | Multiplate wet Type |
Starting system | Kick start / Self start |
Brake |
Front Brake | Disc (240 mm) |
Rear Brake | Internal expanding shoe type (130 mm) |
ABS | - |
Suspension |
Front Suspension | Telescopic hydraulic shock absorbers |
Rear Suspension | Rectangular swing arm with adjustable hydraulic shock absorber |
Wheels & Tyres |
Front Tyre | 2.75 x 18 - 42 P / 4 PR |
Rear Tyre | 3.00 x 18 - 52 P / 6 PR |
Wheel Type | Alloy |
Tubeless Tyres | yes |
Battery |
Battery Type | MF battery |
Capacity | 2.5 Ah (Kick) / 7 Ah (Self) |
Voltage | 12 V |
Instrument Console |
Speedometer | Analogue |
Odometer | Analogue |
Engine RPM meter | - |
Fuel Gauge | Analogue |
Lighting |
Head Light | 12 V -35 W / 35W - Halogen bulb (Multi Reflector Type) |
Tail Light | 12 V - 5 W / 21 W (Multi-Reflector Type) |
Dimension |
Overall Length | 2040 mm |
Overall Width | 760 mm |
Overall Height | 1120 mm |
Ground Clearance | 160 mm |
Seat Height | 800 mm |
Wheelbase | 1290 mm |
Kerb/Wet Weight | 134 Kg (Kick) / 138 Kg (Self) |
Fuel Tank Capacity | 12.5 Liter |
Reserve Fuel Capacity | 2.3 Liter |
